In automotive production lines, hose performance directly affects transfer stability, adhesive consistency, and equipment reliability. When heated media must move through glue pump systems under pressure, the hose is not just a connection part. It becomes a critical component in maintaining process continuity and coating quality.
Shenzhen Jingcheng’s Automotive Production Line Hose is designed for this type of industrial application. According to your catalog, it is suitable for various imported and domestic glue pumps, including SCA, ATN, and GRACO systems. The catalog also notes that Jingcheng has earned recognition from many glue pump manufacturers at home and abroad through strong technical capability and stable hose quality, helping build a good reputation in the coating industry.
This hose is designed for production-line transfer systems where both temperature control and pressure resistance matter. In automotive and industrial coating environments, hose failure or instability can affect not only transfer efficiency, but also application consistency and maintenance cost.
Your catalog states that this hose has a maximum heat resistance of up to 200°C, with higher-temperature customization available on request. It also uses uniformly braided heating elements to reduce temperature distribution differences along the inner wall, while high-insulation-efficiency materials are used to support better thermal performance.
This hose is positioned for automotive production line use, especially in glue pump and coating-related transfer systems. That gives it a clearer industrial focus than a general-purpose heated hose.
The catalog specifically mentions compatibility with SCA, ATN, GRACO, as well as other imported and domestic glue pumps. This makes the product more attractive for OEMs, system integrators, and users already working with those platforms.
The product offers a maximum heat resistance of up to 200°C, making it suitable for heated transfer applications in coating and glue delivery systems. Higher-temperature customization is available on request if needed.
Unlike many low-pressure heated hoses, this product belongs to the low temperature high pressure category. The parameter table shows significantly higher working and burst pressure values, making it suitable for more demanding pressurized transfer conditions.
The hose uses uniformly braided heating elements to minimize inner-wall temperature differences and is made with high-insulation-efficiency materials to improve temperature stability during transfer. These design points are important in production environments where stable media performance matters.
Item | Our Data |
|---|---|
Product Name | Automotive Production Line Hose |
Product Category | Low Temperature High Pressure Heated Hose |
Main Applications | Automotive production lines, glue pump systems, coating industry |
Compatible Equipment | Imported and domestic glue pumps, including SCA, ATN, GRACO |
Market Positioning | Trusted by many glue pump manufacturers at home and abroad |
Max Heat Resistance | Up to 200°C |
Higher Temperature Option | Available on request |
Heating Structure | Uniformly braided heating elements |
Insulation Design | High-efficiency insulation materials |
The above product description and feature points are stated in the automotive production line hose section of your catalog.
I.D. | O.D. (mm ±0.2) | Working Pressure (bar) | Working Pressure (psi) | Burst Pressure (bar) | Burst Pressure (psi) | Min. Bend Radius (mm) |
|---|---|---|---|---|---|---|
3/8" | 15.7 | 475 | 6888 | 1900 | 27550 | 110 |
1/2" | 19.7 | 450 | 6525 | 1800 | 26100 | 150 |
5/8" | 22.5 | 400 | 5800 | 1600 | 23200 | 175 |
3/4" | 20 | 300 | 4350 | 1200 | 17400 | 200 |
1" | 25 | 275 | 3988 | 1100 | 15950 | 240 |
These specifications are listed in the product parameter table for the automotive production line hose on page 9 of the PDF.
These figures are especially important because this product is not only about heating. It is also about high-pressure transfer performance.
For example:
the working pressure values up to 475 bar indicate strong pressure capability,
the burst pressure values up to 1900 bar highlight a high-strength hose structure,
and the 200°C maximum temperature supports heated industrial transfer in coating and adhesive processes.
For buyers in automotive production and glue pump systems, this combination of temperature control and pressure resistance is what makes the product more application-ready.
This product is well suited for:
automotive production lines
industrial glue pump systems
heated coating transfer systems
imported and domestic adhesive delivery equipment
pressurized heated hose applications in manufacturing
These applications are directly supported by the product positioning in your catalog.
Your catalog states that Shenzhen Jingcheng has won recognition in multiple industries through stable quality and high-quality service, and that its heated hose solutions are used in sectors including automotive coating production. The company profile also states that it focuses on the R&D and production of PTFE hoses, PA hoses, PTFE high-pressure hoses, and PTFE electrically heated hoses, while providing complete thermal fluid insulation and transfer solutions.
That matters for this product category because automotive production users do not just need a hose supplier. They need a manufacturer that understands heated transfer, pressure resistance, and long-term reliability in real production environments.
