In food transfer systems, hose performance directly affects temperature stability, media consistency, and overall equipment reliability. When the transferred medium needs to remain at a controlled temperature, an ordinary hose is often not enough. Once temperature drops during transfer, flow stability may change, product consistency may be affected, and the overall process can become less efficient.
That is why a purpose-built constant temperature water heating hose matters. Based on your catalog, this product is suitable for various food transfer equipment, uses a custom food-grade inner tube, and supports full customization according to customer requirements. For applications where temperature-controlled transfer and food-grade material compatibility are both important, this type of hose offers a more suitable solution than a standard transfer line.
This product is specifically described as suitable for various food transfer equipment, giving it a much clearer application focus than a general industrial hose. That makes it more relevant for customers looking for transfer solutions in food-related systems.
One of the strongest points in your catalog is the use of a custom food-grade inner tube. That matters because inner tube material is critical in applications where media compatibility and transfer cleanliness are important.
The catalog explicitly states that all hose lines can be customized according to requirements. This is a major advantage for equipment makers and end users who need non-standard lengths, structures, fittings, or other project-specific details.
The hose offers a maximum heat resistance of up to 100°C, which suits many constant-temperature water heating and food transfer applications. For projects with special requirements, further customization is available on request.
The hose uses uniformly braided heating elements to reduce inner-wall temperature variation and is manufactured with high-insulation-efficiency materials to help maintain transfer temperature more consistently.
Item | Our Data |
|---|---|
Product Name | Constant Temperature Water Heating Hose |
Application Direction | Food transfer equipment |
Inner Tube Material | Custom food-grade inner tube |
Customization | All hose lines can be customized according to requirements |
Max Heat Resistance | Up to 100°C |
Higher Temperature Option | Available on request |
Heating Structure | Uniformly braided heating elements |
Insulation Design | High-efficiency insulation materials |
These product details come from the page 12 product section in your catalog.
I.D. | O.D. (mm ±0.2) | Working Pressure (bar) | Working Pressure (psi) | Burst Pressure (bar) | Burst Pressure (psi) | Min. Bend Radius (mm) |
|---|---|---|---|---|---|---|
1/4" | 9 | 173 | 2501 | 690 | 10005 | 30 |
5/16" | 11 | 158 | 2284 | 630 | 3915 | 40 |
3/8" | 12.4 | 135 | 1958 | 540 | 7830 | 60 |
1/2" | 15.9 | 118 | 1704 | 470 | 6815 | 150 |
5/8" | 19 | 88 | 1269 | 350 | 5075 | 180 |
3/4" | 22.6 | 85 | 1234 | 340 | 4930 | 260 |
1" | 29.5 | 75 | 1088 | 300 | 4350 | 300 |
These specifications are listed in the parameter table shown with this product section.
These figures help buyers judge whether the hose can match their equipment layout, flow requirement, and installation design.
For example:
the up to 100°C heat resistance fits many constant-temperature transfer scenarios,
the food-grade inner tube supports better application matching for food-related systems,
and the 1/4" to 1" size range provides flexibility for different equipment structures.
For temperature-controlled transfer applications, hose selection is not only about size. It is also about temperature stability, inner tube suitability, and customization flexibility.
This product is well suited for:
food transfer equipment
constant temperature water heating systems
temperature-controlled transfer lines
custom hose applications requiring food-grade inner tube
equipment that needs stable heated transfer below 100°C
These use scenarios are based on the product section shown on page 12 of your catalog.
Your catalog states that Shenzhen Jingcheng focuses on the R&D and production of PTFE hoses, PA hoses, PTFE high-pressure hoses, and PTFE electrically heated hoses, while also providing complete thermal fluid insulation and transfer solutions. The catalog also highlights your ability to customize different heated hose types according to industry requirements and the temperature, viscosity, and flow characteristics of the medium. That customization capability is especially valuable for products like this, where transfer medium, application environment, and equipment interface may vary significantly.
For buyers, that means this product is backed not only by technical data, but also by real heated hose manufacturing and customization experience.
