SHENZHEN, China — Shenzhen Jingcheng High-tech Co., Ltd. (Jingcheng) is offering its JCC-20000-PTFE smooth inner, corrugated outer PTFE spring hose for process lines that run hot, pressurized and corrosive at the same time.
The hose has three layers:
a smooth PTFE inner tube
a 304 stainless steel spiral spring middle layer
a corrugated outer profile
It is rated from -65°C to 260°C. It comes in seven standard sizes from 1/4" to 1", and custom builds are available to customer parameters.
A flexible hose on a hot oil, steam or corrosive chemical line carries three loads at once: chemical, thermal and mechanical. PTFE handles the chemical and thermal loads well. The mechanical load, meaning pressure combined with bending, is where unreinforced hoses struggle. In hot service, that kind of failure is a safety incident, not just a maintenance ticket.
"Hot-line hose problems rarely come from the chemical. They come from pressure and bending the hose was never built for. That's why this design separates the jobs: PTFE for the medium, steel for the pressure."
— [Name], [Title], Jingcheng
Smooth inner wall
The medium touches only a smooth PTFE surface.
There are no internal ridges where residue can settle.
Lines flush and drain more completely between batches and product changes.
304 spiral spring
The stainless steel spring keeps the hose round under pressure and through bends.
At 1/4", it gives a working pressure of 396 psi (2.64 MPa) and a burst pressure of 1276 psi (8.8 MPa).
Corrugated outer profile
Flexibility comes from the outside of the hose, not from the flow path.
Minimum bend radius is 19 mm at 1/4" and 75 mm at 1".
Documented material
The hose is certified to ISO 9001:2015, US FDA 21 CFR 177.1550 and SGS.
Our Data: JCC-20000-PTFE Smooth Inner, Corrugated Outer PTFE Spring Hose
No. | Inner diameter | ID (mm ±0.3) | OD (mm ±0.3) | Working pressure (psi) | Working pressure (MPa) | Burst pressure (psi) | Burst pressure (MPa) | Min. bend radius (inch) | Min. bend radius (mm) |
|---|---|---|---|---|---|---|---|---|---|
JCC-20006-PTFE | 1/4" | 6.8 | 8.35 | 396 | 2.64 | 1276 | 8.8 | 0.75 | 19 |
JCC-20008-PTFE | 5/16" | 7.9 | 10.3 | 378 | 2.52 | 1218 | 8.4 | 0.75 | 19 |
JCC-20010-PTFE | 3/8" | 10 | 11.93 | 360 | 2.4 | 1160 | 8 | 0.98 | 25 |
JCC-20013-PTFE | 1/2" | 13.6 | 15.1 | 270 | 1.8 | 870 | 6 | 1.50 | 38 |
JCC-20016-PTFE | 5/8" | 16.7 | 18.3 | 236.83 | 1.63 | 725 | 5 | 1.97 | 50 |
JCC-20019-PTFE | 3/4" | 19.8 | 22 | 203 | 1.4 | 609 | 4.2 | 2.48 | 63 |
JCC-20025-PTFE | 1" | 26.4 | 29.4 | 180 | 1.2 | 580 | 4 | 2.95 | 75 |
The JCC-20000-PTFE is built to transport:
highly corrosive chemicals
hot air
hot oil
steam
It serves four industries:
Chemical: corrosive media under pressure. The medium touches only PTFE, and the spring carries the load.
Food: product, hot oil and steam transfer, with FDA 21 CFR 177.1550 documentation.
Cosmetics: the smooth inner wall drains cleanly, which supports changeovers between formulations.
Pharmaceutical: process lines that need a PTFE contact surface together with pressure and temperature capacity.
The JCC-20000-PTFE is available now in seven standard sizes, and Jingcheng can build to customer parameters. Getting the right size confirmed takes one message. Send Jingcheng five details:
inner diameter
medium
operating temperature
working pressure
the tightest bend on your route
For lines that run at lower pressure or need sizes up to 2", Jingcheng also offers the fully corrugated JCC-10000-PTFE series.
