A medical-grade heated transfer hose is designed for medical equipment that requires controlled-temperature material transfer, clean internal surfaces and customized equipment connections.
Temperature-sensitive medical or process materials may become more viscous, less stable or difficult to transfer when the temperature decreases. A heated hose helps maintain more consistent material conditions between equipment sections.
Shenzhen Jingcheng High-tech manufactures customized medical heated hoses using selected medical-grade material-contact inner tubes, uniform heating structures and equipment-specific fittings.
A medical-grade heated hose is a flexible electrically heated transfer line designed for medical equipment and related process systems.
The complete assembly may include:
Customized medical-grade inner tube
Pressure reinforcement
Uniform heating elements
Thermal insulation
Protective outer covering
Temperature sensor
Material fittings
Electrical connector
The final structure is selected according to the transferred medium, temperature, pressure, cleanliness requirements and equipment interface.
Temperature variation can affect material viscosity and flow stability.
An ordinary hose may allow the transferred medium to cool, potentially causing:
Increased viscosity
Unstable flow rate
Reduced process consistency
Material accumulation
Hose blockage
Longer cleaning time
Increased equipment pressure
Production interruption
A medical heated hose helps maintain more stable transfer conditions throughout the system.
The material-contact inner tube can be selected according to the medical equipment, transferred medium and process requirements.
The standard product supports operating temperatures up to 230°C.
The actual temperature should be confirmed according to the medium, inner-tube material and complete hose design.
Uniformly arranged heating elements help reduce temperature differences and cold spots along the hose.
The insulation structure reduces heat loss and helps maintain stable internal temperature.
Hose length, diameter, fittings, voltage, power, sensor and electrical connector can be matched to the medical equipment.
Samples can be manufactured for compatibility testing before larger production orders.
Medical equipment material transfer
Temperature-controlled medical systems
Diagnostic equipment
Laboratory medical devices
Pharmaceutical processing equipment
Medical material dispensing
Heated liquid transfer
Medical coating equipment
Customized healthcare machinery
Precision process fluid systems
Item | Available Options |
|---|---|
Product Name | Medical-Grade Heated Transfer Hose |
Maximum Temperature | Up to 230°C |
Inner Tube | Medical-grade material option |
Heating Structure | Uniformly distributed heating elements |
Voltage | 110V / 220V / 380V / Custom |
Sensor | PT100 / PT1000 / J type / K type / Custom |
Hose Length | Customized |
Inner Diameter | Customized |
Fluid Fittings | Customized |
Electrical Connector | Customized |
Special Cleaning | Available according to requirements |
Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Minimum Bending Radius |
1/4” | 9 mm | 173 bar / 2,501 psi | 690 bar / 10,005 psi | 30 mm |
5/16” | 11 mm | 158 bar / 2,284 psi | 630 bar / 3,915 psi | 40 mm |
3/8” | 12.4 mm | 135 bar / 1,958 psi | 540 bar / 7,830 psi | 60 mm |
1/2” | 15.9 mm | 118 bar / 1,704 psi | 470 bar / 6,815 psi | 150 mm |
5/8” | 19 mm | 88 bar / 1,269 psi | 350 bar / 5,075 psi | 180 mm |
3/4” | 22.6 mm | 85 bar / 1,234 psi | 340 bar / 4,930 psi | 260 mm |
1” | 29.5 mm | 75 bar / 1,088 psi | 300 bar / 4,350 psi | 300 mm |
These values are catalog reference data. Final operating pressure depends on temperature, inner-tube structure, fittings and complete assembly design.
Please provide:
Transferred medium
Required inner-tube material
Working temperature
Working pressure
Required flow rate
Hose length
Inner diameter
Voltage and power
Sensor type
Inlet and outlet fittings
Electrical connector
Equipment model
Cleaning or packaging requirements
Original hose sample or drawing
We design hose assemblies according to actual equipment and material requirements.
Direct production supports faster technical communication and shorter procurement chains.
Length, diameter, fittings, heating power, sensor and electrical interface can all be customized.
We support replacement hoses, prototypes and project production.
Samples can be manufactured for equipment and medium compatibility testing.
