An anti-static PTFE hose is designed for applications where static electricity control, chemical resistance and safe fluid transfer are important. In many industrial systems, especially when transferring flammable liquids, chemical fluids or powder-related media, static charge accumulation may create safety risks or process instability.
Shenzhen Jingcheng High-tech manufactures customized anti-static PTFE hose solutions, including anti-static smooth bore PTFE hose, anti-static corrugated PTFE hose, anti-static inner smooth outer corrugated PTFE hose and all-black conductive corrugated PTFE hose. These hoses are suitable for chemical liquid treatment, flammable liquid transfer, static coating, food industry and other demanding applications.
An anti-static PTFE hose is a PTFE hose designed to reduce static charge accumulation during fluid transfer. Compared with ordinary PTFE hoses, anti-static PTFE hoses provide better static dissipation performance while maintaining the key advantages of PTFE, such as chemical resistance, temperature resistance, low friction and non-stick properties.
Anti-static PTFE hoses are especially useful when the transferred medium or working environment may generate electrostatic charge.
During fluid transfer, friction between the medium and the hose inner wall can generate static electricity. In some applications, this may create safety risks, especially when transferring flammable liquids, solvents, fuel, chemical fluids or materials used in coating processes.
A properly designed anti-static PTFE hose helps reduce static accumulation and supports safer, more stable system operation.
This type provides a smooth inner wall for stable flow, lower friction and easier cleaning. It is suitable for clean fluid transfer and applications requiring controlled static performance.
The corrugated structure provides better flexibility and bending performance, making it suitable for compact equipment layouts and moving connection points.
This structure combines a smooth inner wall with an outer corrugated design, helping balance clean transfer performance and flexibility.
This hose is designed for stronger conductive performance and applications where static dissipation is a key requirement.
The anti-static PTFE structure helps reduce static charge accumulation during fluid transfer and supports safer system operation.
Anti-static PTFE hoses can be used in both low-temperature and high-temperature environments, with a typical temperature range from approximately -60°C to +260°C, depending on hose structure and working conditions.
PTFE provides excellent resistance to many chemicals, solvents, acids, alkalis and corrosive media. It is also highly inert and not easily affected by most chemicals.
PTFE has a very low friction coefficient, helping improve flow performance and reduce material adhesion inside the hose.
Anti-static PTFE hoses are lightweight and flexible, making them easier to install and use in equipment systems.
The smooth PTFE surface provides natural lubrication characteristics and good wear performance under suitable working conditions.
Customers can choose smooth bore, corrugated, inner smooth outer corrugated or conductive black hose structures according to the application.
Our anti-static PTFE hose can be used in:
Chemical liquid treatment
Flammable liquid transfer
Solvent transfer systems
Fuel transfer systems
Static coating industry
Food industry
Chemical dosing equipment
Industrial fluid transfer
Laboratory chemical systems
Process equipment connection lines
Corrosive media transfer
Item | Available Options |
|---|---|
Product Name | Anti-Static PTFE Hose |
Product Series | Anti-static PTFE hose series |
Available Structures | Smooth bore, corrugated, inner smooth outer corrugated, all-black conductive corrugated |
Material | Anti-static PTFE |
Temperature Range | Approx. -60°C to +260°C, depending on structure |
Main Advantages | Anti-static, chemical resistant, low friction, lightweight, flexible |
Application | Chemical liquid treatment, flammable liquid transfer, static coating, food industry |
Customization | Available |
Hose Assembly | Custom fittings, length and structure available |
Shenzhen Jingcheng High-tech Co., Ltd. is a professional PTFE hose manufacturer specializing in PTFE hoses, PTFE high-pressure hoses, anti-static PTFE hoses, PA hoses and electric heated hoses. We provide customized hose solutions for chemical processing, flammable liquid transfer, food equipment, coating systems, pharmaceutical applications, fuel systems and industrial fluid transfer.
For global buyers, equipment manufacturers and industrial distributors, we offer factory-direct customized PTFE hose solutions with stable quality, flexible customization, short lead time and sample support.
We manufacture PTFE hoses directly in China, helping customers reduce sourcing cost and improve supply chain efficiency.
We can supply different anti-static PTFE hose structures according to your application, including smooth bore, corrugated and conductive black hose options.
Anti-static PTFE hoses maintain the excellent chemical resistance of PTFE while improving static dissipation performance.
We can customize hose length, inner diameter, fittings, connector type, bending radius and hose assembly structure according to drawings, samples or working conditions.
This hose is suitable for flammable liquids, chemical solvents, coating systems and other applications where static control is important.
