In hot melt adhesive systems, hose performance directly affects temperature stability, adhesive flow, equipment uptime, and final bonding quality. When the hose cannot maintain consistent heat, the adhesive may thicken, cool too quickly, or flow unevenly, leading to application inconsistency and higher maintenance cost.
That is why a purpose-built hot melt glue hose matters. Shenzhen Jingcheng’s hot melt glue hose is designed for hot melt glue machines and PUR adhesive systems, while also supporting compatibility with a range of imported equipment brands listed in the catalog, including Nordson and other major glue machine platforms. The product is built to deliver stable heating, dependable insulation, and durable service life in demanding adhesive transfer applications.
A hot melt hose is not simply a transfer line. It is a thermal control component. It must keep the adhesive at the right temperature from the melting unit to the application point, while resisting heat loss, maintaining flow consistency, and supporting long-term machine operation.
According to your catalog, this product is suitable for various hot melt glue machines and PUR glue machines. The catalog also notes that Jingcheng’s hot melt glue hose moves beyond the conventional manual winding approach and is produced with fully automated winding equipment, helping improve product consistency, qualification rate, and durability.
This hose is purpose-built for hot melt and PUR systems rather than being a general industrial hose. That means it is better matched to the temperature-holding and flow-stability demands of adhesive application equipment.
Your catalog states that the hose has a maximum heat resistance of up to 230°C, with higher temperature customization available on request. This gives it the thermal range needed for many industrial adhesive transfer applications.
The heating layer is made of uniformly braided heating elements, which helps minimize temperature distribution differences along the inner wall. In real production, this supports more consistent adhesive temperature and more stable transfer behavior.
The catalog states that the hose is manufactured with high-insulation-efficiency materials while taking surface temperature into account. This helps reduce heat loss and supports better thermal retention during operation.
A standout point in your catalog is that Jingcheng’s hot melt glue hose is made using fully automated winding equipment, replacing older manual winding methods. This is important because it suggests stronger manufacturing consistency and more durable finished hose quality.
| Item | Our Data |
|---|---|
| Product Name | Hot Melt Glue Hose |
| Product Category | High Temperature Low Pressure Heated Hose |
| Main Applications | Hot melt glue machines, PUR glue machines |
| Compatible Equipment | Can match imported glue machines listed in the catalog, including Nordson and other major brands |
| Max Heat Resistance | Up to 230°C |
| Higher Temperature Option | Available on request |
| Heating Structure | Uniformly braided heating elements |
| Insulation Design | High-efficiency insulation materials |
| Manufacturing Method | Fully automated winding equipment |
| Product Benefit | Qualified quality and durable service life |
The above product positioning and feature points are stated in the product section for the hot melt glue hose.
| I.D. | O.D. (mm ±0.2) | Working Pressure (bar) | Working Pressure (psi) | Burst Pressure (bar) | Burst Pressure (psi) | Min. Bend Radius (mm) |
|---|---|---|---|---|---|---|
| 1/4" | 9 | 173 | 2501 | 690 | 10005 | 30 |
| 5/16" | 11 | 158 | 2284 | 630 | 3915 | 40 |
| 3/8" | 12.4 | 135 | 1958 | 540 | 7830 | 60 |
| 1/2" | 15.9 | 118 | 1704 | 470 | 6815 | 150 |
| 5/8" | 19 | 88 | 1269 | 350 | 5075 | 180 |
| 3/4" | 22.6 | 85 | 1234 | 340 | 4930 | 260 |
| 1" | 29.5 | 75 | 1088 | 300 | 4350 | 300 |
These are the catalog specifications shown for the hot melt glue hose size range.
These numbers are not just reference values. They help buyers quickly judge whether the hose is suitable for their machine layout, adhesive viscosity, pressure conditions, and installation space.
For example:
the 230°C temperature capability supports many hot melt and PUR processing conditions,
the multiple inner diameter options make it easier to match different output requirements,
and the minimum bend radius data is useful when hose routing space is limited inside the machine frame.
For hot melt systems, a good hose is not only about temperature. It is also about routing, fit, durability, and repeatable adhesive delivery.
A reliable hot melt glue hose can make the difference between stable adhesive application and recurring production problems. When the hose is properly designed for heated adhesive transfer, it helps maintain temperature, support smooth flow, reduce downtime, and improve overall process consistency.
Shenzhen Jingcheng’s hot melt glue hose combines up to 230°C heat resistance, uniform braided heating, high-efficiency insulation, automated winding production, and a broad size range for industrial hot melt and PUR systems. For customers looking for a more durable and better-matched heated hose solution, this product offers both practical performance and strong customization
