In fluid transfer systems where flexibility is critical, a standard smooth PTFE hose is not always enough. Some installations require tighter routing, more frequent bending, and better adaptability to compact layouts. In those cases, hose structure matters just as much as chemical resistance.
That is where a PTFE convoluted hose becomes a stronger solution. Shenzhen Jingcheng’s PTFE inner spiral corrugated hose is designed for applications that demand both PTFE chemical compatibility and excellent bending performance. According to your brochure, both the inner and outer walls are corrugated PTFE, giving the hose extremely strong bending performance, while maintaining a wide operating temperature range of -70°C to 260°C. It is positioned for use in the pharmaceutical, food, and chemical industries.
Unlike a smooth bore PTFE hose, this product is built with a corrugated inner and outer wall design. That structural difference is important because it gives the hose more flexibility and makes it easier to install in systems where routing space is limited.
Your brochure specifically states that this is a special PTFE hose with corrugated inner and outer walls, and that it has extremely strong bending performance. For customers who need PTFE tubing but also need easier installation and better flexibility, this creates a strong practical advantage.
The biggest feature of this hose is flexibility. Because both the inner and outer walls are corrugated, the hose offers very strong bending performance, making it more suitable for compact equipment layouts and installations requiring tighter routing.
The product has a temperature range of -70°C to 260°C, which allows it to work across a wide range of industrial conditions. This makes it suitable for both low-temperature and high-temperature transfer applications.
As a PTFE hose, it retains the material advantages users expect from PTFE, including compatibility with demanding media and suitability for industries where cleanliness and chemical resistance matter.
The brochure explicitly states that this hose is suitable for the pharmaceutical industry, food industry, and chemical industry. That broad application range makes it attractive to buyers who need one flexible hose solution across several process environments.
The parameter table covers sizes from 1/4" to 2", and the brochure notes that the hose can be customized according to parameter requirements. This gives engineers more flexibility when matching different system designs.
Item | Our Data |
|---|---|
Product Name | PTFE Inner Spiral Corrugated Hose |
Model Series | JCC-10000-PTFE |
Product Structure | Inner and outer walls are both corrugated PTFE hose |
Main Feature | Extremely strong bending performance |
Temperature Range | -70°C to 260°C |
Main Industries | Pharmaceutical industry, food industry, chemical industry |
Custom Support | Customizable according to parameter requirements |
These product details are stated on the second product page of your PTFE cold hose brochure.
No. | Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Minimum Bending Radius |
|---|---|---|---|---|---|
JCC-10004-PTFE | 1/4" / 6.5 mm | 10.6 mm | 60 psi / 0.4 MPa | 210 psi / 1.4 MPa | 0.79" / 20 mm |
JCC-10008-PTFE | 5/16" / 8 mm | 12.3 mm | 60 psi / 0.4 MPa | 210 psi / 1.4 MPa | 0.87" / 22 mm |
JCC-10010-PTFE | 3/8" / 10 mm | 15 mm | 60 psi / 0.4 MPa | 210 psi / 1.4 MPa | 1.02" / 26 mm |
JCC-10013-PTFE | 1/2" / 13 mm | 17.9 mm | 60 psi / 0.4 MPa | 210 psi / 1.4 MPa | 1.02" / 26 mm |
JCC-10016-PTFE | 5/8" / 16 mm | 21.9 mm | 45 psi / 0.3 MPa | 180 psi / 1.2 MPa | 1.26" / 32 mm |
JCC-10019-PTFE | 3/4" / 19 mm | 26.4 mm | 45 psi / 0.3 MPa | 180 psi / 1.2 MPa | 2.17" / 55 mm |
JCC-10025-PTFE | 1" / 25 mm | 35 mm | 45 psi / 0.3 MPa | 150 psi / 1.0 MPa | 3.15" / 80 mm |
JCC-10032-PTFE | 1-1/4" / 32 mm | 39 mm | 38 psi / 0.3 MPa | 135 psi / 0.9 MPa | 3.94" / 100 mm |
JCC-10038-PTFE | 1-1/2" / 38 mm | 45 mm | 38 psi / 0.3 MPa | 135 psi / 0.9 MPa | 3.94" / 100 mm |
JCC-10050-PTFE | 2" / 50 mm | 59.5 mm | 30 psi / 0.2 MPa | 120 psi / 0.8 MPa | 4.92" / 125 mm |
These specifications are shown in the product table for the second PTFE hose product in your brochure.
These values help buyers determine whether the hose can match their installation space, bending requirements, and system pressure.
For example:
the very small minimum bending radius is a major advantage in compact installations,
the -70°C to 260°C temperature range supports broad process conditions,
and the 1/4" to 2" size range allows use across both smaller and larger transfer systems.
For many pharmaceutical, food, and chemical systems, the real value of this hose is not just PTFE resistance. It is PTFE resistance with much better flexibility.
This product is well suited for:
pharmaceutical transfer systems
food processing transfer lines
chemical fluid handling systems
compact equipment layouts requiring flexible hose routing
PTFE applications where strong bending performance is important
These use scenarios are directly supported by the brochure description.
Your brochure presents Jingcheng as a professional PTFE hose manufacturer focused on PTFE hose production and customized transfer solutions. For buyers, this matters because products like PTFE convoluted hose depend heavily on manufacturing consistency, material quality, and dimensional control.
For practical projects, customers are not only buying a hose type. They are choosing a supplier that can offer the right structure, the right size range, and the right production stability.
