Paraffin pipes are widely used in various industrial applications due to their excellent low-temperature and pressure resistance. Particularly suitable for systems that require insulation and heating, these pipes prevent freezing or increased viscosity of transported fluids. Customizable to meet specific needs, our paraffin pipes are designed to ensure efficient and stable operation in various environments, making them an ideal choice for your industrial systems.
Temperature Range: Maximum temperature tolerance of 100°C, meeting the needs of most low-temperature, low-pressure applications.
Customization Options: Tailor-made designs available, including pipe length, diameter, sensor types, and more.
Safety Features: High insulation efficiency materials and uniformly braided heating elements to enhance safety and minimize risks like short circuits and leakage.
Paraffin pipes are designed specifically for low-temperature, low-pressure environments, offering superior insulation and heating performance. These pipes effectively prevent the freezing or thickening of fluids during transportation, ensuring stable operation. Whether in harsh weather conditions or extreme temperatures, paraffin pipes provide long-lasting, reliable performance, guaranteeing the efficiency of your production line.
| Inner Diameter (mm) | Outer Diameter (mm) | Working Pressure (MPa) | Burst Pressure (MPa) | Minimum Bend Radius (mm) |
|---|---|---|---|---|
| 1/4" (6.35mm) | 9 | 1.5 | 6.0 | 30 |
| 3/8" (9.53mm) | 11 | 1.8 | 7.0 | 40 |
| 1/2" (12.7mm) | 15.9 | 1.6 | 6.5 | 50 |
Pipe Length: Custom lengths available from 0.5 meters to 10 meters.
Pipe Diameter: Custom diameters from 6mm to 50mm.
Sensor Options: Supports PT100, K-type thermocouple, and more.
Connector Specifications: Available in American, British, or metric threads.
Example Model: JCH-200-16-B-3X220-P2-8-N
200: Working temperature (200°C)
16: Inner diameter 16mm
B: Stainless steel corrugated tube lining
3X220: Three-phase 220V working voltage
P2: PT100 dual-wire sensor
8: Working pressure 8MPa
To ensure optimal performance of your paraffin pipes, please provide the following details for an accurate quote:
Required pipe length
Desired inner and outer diameters
Working pressure and maximum burst pressure
Voltage and sensor preferences
Shenzhen Jingcheng High-tech Co., Ltd. specializes in providing high-performance custom solutions for industrial hoses, including paraffin pipes. With over 15 years of experience, we manufacture our products using the highest industry standards in our state-of-the-art facilities in Zhongshan. We prioritize short lead times and reliable delivery, ensuring your production line runs smoothly.
