In many transfer systems, users need more than pressure resistance alone. They also want a hose that is lighter, easier to handle, and better suited for dynamic or mobile equipment. This is especially important in industries where hose weight, flexibility, anti-static performance, and chemical compatibility all affect real-world performance.
That is where an aramid braided lightweight PTFE hose becomes a highly practical solution. Shenzhen Jingcheng’s PTFE Aramid Braided Lightweight Hose is designed with a Teflon straight tube inner layer and an aramid braided outer layer, offering a lighter-weight alternative to heavier steel-reinforced hose structures while still maintaining strong media compatibility and anti-static performance. According to your brochure, this hose operates within a temperature range of -65°C to 220°C and is suitable for transferring fuel, gas, strong acids, strong alkalis, and other organic solvents.
Unlike a traditional stainless-steel braided PTFE hose, this product replaces the outer reinforcement with an aramid braided layer. That changes the value proposition significantly.
This hose is designed for users who need:
lower hose weight
better handling and easier routing
anti-static performance
chemical compatibility with demanding media
suitability for vehicle, hydraulic, aerospace, and transport systems
The brochure specifically states that the hose has an excellent anti-static effect, which makes it especially useful in applications involving fuel, gas, and chemically active media where electrostatic buildup can become a concern.
The biggest structural difference of this product is the aramid braided outer layer. Compared with heavier steel-braided hose constructions, this design supports a lighter overall hose body, which is beneficial in mobile systems, transport equipment, and applications where hose weight matters.
Your brochure explicitly highlights that the hose has an excellent anti-static effect. This is a strong selling point for fuel, gas, and solvent-related transfer systems, where reducing static accumulation can improve operational safety and performance.
The inner layer is a Teflon straight tube, which helps maintain PTFE’s well-known advantages in chemical resistance, media compatibility, and clean internal flow.
The brochure states that this hose can be used for fuel, gas, strong acids, strong alkalis, and various organic solvents. That gives it a broad range of possible industrial and technical uses.
One of the strongest positioning points in the brochure is its wide application range. It is listed for hazardous chemical transfer, fuel/coolant/lubricant delivery pipelines, and systems involving hydraulic machinery, trains, automobiles, ships, aircraft, rockets, spacecraft, and satellites. That gives the product a strong high-performance and transport-industry orientation.
Item | Our Data |
|---|---|
Product Name | PTFE Aramid Braided Lightweight Hose |
Model Series | JCC-04100-PTFE |
Inner Structure | Teflon straight tube |
Outer Structure | Aramid braided outer layer |
Key Feature | Excellent anti-static effect |
Temperature Range | -65°C to 220°C |
Main Media | Fuel, gas, strong acids, strong alkalis, various organic solvents |
Main Applications | Hazardous chemical transfer, fuel/coolant/lubricant delivery lines, hydraulic and transport systems |
Custom Support | Customizable according to requirements |
These product details are stated on the tenth product page of your PTFE cold hose brochure.
No. | Inner Diameter | Outer Diameter | Outer Diameter of Woven Products | Working Pressure | Burst Pressure | Minimum Bending Radius |
|---|---|---|---|---|---|---|
JCC-04110-PTFE | 3/8" / 10 mm | 13.1 mm | 15.6 mm | 5800 psi / 40.0 MPa | 23200 psi / 160 MPa | 3.15" / 80 mm |
JCC-04113-PTFE | 1/2" / 13 mm | 16.5 mm | 18.6 mm | 5437.5 psi / 37.5 MPa | 21750 psi / 150 MPa | 5.91" / 150 mm |
JCC-04116-PTFE | 5/8" / 16 mm | 19.4 mm | 23.2 mm | 4785 psi / 33.0 MPa | 19140 psi / 132 MPa | 7.09" / 180 mm |
JCC-04119-PTFE | 3/4" / 19 mm | 23.1 mm | 26.6 mm | 4241.3 psi / 29.25 MPa | 16965 psi / 117 MPa | 11.81" / 300 mm |
JCC-04125-PTFE | 1" / 25.4 mm | 30.5 mm | 33 mm | 3552.5 psi / 24.5 MPa | 14210 psi / 98 MPa | 15.75" / 400 mm |
These specifications are shown in the product table for the tenth PTFE hose product in your brochure.
These numbers clearly show that this hose is not just lightweight. It is also built for demanding service conditions.
For example:
working pressure up to 40 MPa shows that this hose can still deliver strong pressure performance despite its lighter outer construction
the excellent anti-static effect makes it more suitable for fuel, gas, and solvent transfer
and the lighter aramid braided structure can offer real advantages in mobile systems, transport equipment, and installations where overall hose weight matters
For many users, the key value of this hose is that it combines lighter weight, anti-static performance, and strong media compatibility in one design.
This product is well suited for:
hazardous chemical transfer
fuel transfer systems
gas transfer systems
coolant and lubricant delivery pipelines
hydraulic machinery
trains, automobiles, ships, and aircraft
advanced transport and aerospace systems requiring lightweight anti-static PTFE hose
These application directions are directly supported by the brochure description.
Your brochure presents Jingcheng as a professional PTFE hose manufacturer focused on PTFE hose production and customized transfer solutions. For a product like this, that matters because anti-static performance, braid quality, dimensional control, and media compatibility all depend on manufacturing consistency.
For customers in transport, industrial machinery, or chemical transfer fields, choosing the right supplier means getting more than a hose. It means getting a lightweight, application-matched PTFE transfer solution with dependable structure and stable quality.
