Jingcheng High Temperature High Pressure Special Industry Connection Hose is an electric heated transfer hose designed for special industrial equipment. It is used for stable connection, heat preservation, continuous heating, and pressure-resistant transfer of high-temperature, high-pressure, and high-viscosity materials.
It is not a common transfer hose or a simple insulated hose. It is a customized high-temperature and high-pressure heated hose solution built according to real equipment working conditions.
Product Name: High Temperature High Pressure Special Industry Connection Hose
Product Type: Electric heated hose / High pressure heated hose / Special equipment connection hose
Main Functions: Heating, insulation, pressure resistance, material transfer, equipment connection
Suitable Conditions: High temperature, high pressure, high viscosity, non-standard equipment, imported equipment replacement
Standard Heat Resistance: Up to 230°C
Higher Temperature: Customizable according to working conditions
Pressure Resistance: Customizable up to 40MPa or higher
Inner Tube Material: PTFE inner tube available
Reinforcement Structure: 304 stainless steel pressure-resistant wire
Heating Structure: Uniformly braided heating layer
Customization Options: Length, inner diameter, voltage, power, sensor, connector, and outer protection structure
This high temperature high pressure special industry connection hose is mainly used for pipe connection in domestic and imported special equipment, especially in applications where ordinary hoses cannot meet both temperature and pressure requirements.
It is suitable for:
Special industrial equipment connection
High-pressure material transfer equipment
High-viscosity fluid transfer systems
Imported equipment replacement hoses
Non-standard automation equipment
Thermal fluid insulation transfer systems
Production lines requiring continuous heat tracing
Complex equipment requiring customized connectors
When your equipment requires both stable material temperature and reliable pressure resistance, this type of electric heated hose is more suitable than ordinary industrial hoses.
Many customers face three common problems when using ordinary hoses.
First, the material temperature drops during transfer, causing viscosity increase, slower flow, material residue, or even hose blockage.
Second, ordinary heated hoses can provide insulation, but they may not meet high-pressure working conditions.
Third, ordinary high-pressure hoses can withstand pressure, but they cannot provide continuous heating to keep the material stable.
Jingcheng High Temperature High Pressure Special Industry Connection Hose is designed to solve these problems. It combines continuous heating, heat preservation, pressure resistance, and customized equipment connection in one hose structure, making it suitable for complex industrial applications.
The inner tube is the part that directly contacts the transferred material. This hose can be built with a PTFE inner tube, which provides good temperature resistance, chemical resistance, and low adhesion performance.
For resin, grease, adhesive, high-viscosity materials, or other temperature-sensitive media, the PTFE inner tube helps reduce material adhesion and supports smoother material transfer.
To meet high-pressure working conditions, the hose can be reinforced with 304 stainless steel pressure-resistant wire. This structure improves the overall pressure resistance of the hose and makes it suitable for high-pressure equipment connection and material transfer.
The heating layer is made with uniformly braided heating elements. This helps reduce temperature differences along the inner wall of the hose and keeps the hose in a more stable heating state during operation.
This is especially important for high-viscosity materials. Once the temperature becomes unstable, the material condition may change and affect the output stability of the equipment.
The hose uses high-efficiency insulation materials to reduce heat loss and improve temperature retention. For continuous production equipment, good insulation performance can reduce energy waste and improve overall transfer stability.
Different equipment uses different connector standards. Jingcheng can customize metric, British, American, or non-standard connectors according to the customer’s equipment requirements. Connector angle and connection form can also be customized based on the installation environment.
Suitable for high-temperature working conditions, with standard heat resistance up to 230°C.
Customizable for high-pressure applications, with special requirements up to 40MPa or higher.
PTFE inner tube available for complex media and high-viscosity material transfer.
304 stainless steel wire reinforcement improves hose pressure resistance.
Uniformly braided heating layer reduces local temperature differences and keeps material transfer more stable.
Suitable for both imported equipment replacement and domestic equipment matching.
Customizable according to real working conditions, not limited to standard specifications.
Jingcheng High Temperature High Pressure Special Industry Connection Hose can be customized according to customer equipment parameters.
Customization options include:
Hose length
Inner diameter
Working temperature
Working pressure
Rated power
Working voltage
Sensor type
Connector standard
Connector angle
Outer protection material
Bending radius requirement
Equipment installation method
Common voltage options include 220V, 380V, 110V, and other customized voltages.
Common sensor options include PT100, PT1000, K type, J type, and other customized sensor types according to the temperature control system.
This product is suitable for industrial media that require temperature control and pressure resistance, such as:
Resin materials
Grease materials
Adhesive materials
High-viscosity fluids
Thermal fluid media
Industrial liquids requiring insulation
Materials that may cool down or solidify during transfer
Special media requiring stable temperature control
The final hose structure should be confirmed according to the material temperature, viscosity, corrosiveness, pressure, and equipment connector requirements.
This high temperature high pressure special industry connection hose is suitable for:
Special equipment manufacturers
High-pressure equipment manufacturers
Automation equipment manufacturers
Factories using imported equipment
Customers replacing original equipment hoses
Customers needing non-standard heated hoses
High-viscosity material production lines
Industrial customers requiring stable temperature control
If the customer only needs a common low-pressure transfer hose, this product may be a higher-specification option.
However, if the application involves high temperature, high pressure, insulation, non-standard connectors, or imported equipment replacement, this hose is a more suitable customized solution.
To help us provide a more accurate solution, customers are advised to confirm the following information before inquiry:
What material will be transferred?
What temperature does the material need to maintain?
What is the working pressure?
What hose length is required?
What inner diameter is needed?
What connector standard does the equipment use?
What voltage is required?
What sensor type is needed?
Is it used to replace an imported equipment hose?
With this information, we can recommend a more suitable hose structure, connector type, and electrical configuration according to the actual working condition.
Jingcheng has long focused on the research and production of PTFE hoses, PTFE high-pressure hoses, PA hoses, and PTFE electric heat tracing hoses. We can provide thermal fluid insulation and transfer solutions for different industrial applications.
For high temperature high pressure special industry connection hoses, we do not only focus on temperature and pressure data. We also consider the customer’s equipment structure, transferred material, installation method, and temperature control system.
What we provide is not just a standard hose, but a customized heated transfer hose solution that better fits the customer’s real equipment conditions.
