Intro
When weight matters as much as chemical resistance, a standard metal-braided PTFE hose is not always the best fit. For aerospace, transport systems, hydraulic equipment, fuel delivery, and other motion-sensitive assemblies, a lighterhose structure can improve routing, reduce load, and simplify installation.
Our PTFE Aramid Braided Lightweight Hose combines a PTFE inner tube with a high-strength aramid braided outer layer to provide flexible media transfer for demanding industrial environments. According to the catalog page, this hose is designed for fuels, gases, strong acids, strong alkalis, coolants, lubricants, and various organic solvents, with aservice temperature range of -65°C to 220°C.
Performance Highlights
Temperature range: -65°C to 220°C
Working pressure: up to 40 MPa / 5800 psi (design-dependent, based on size)
Burst pressure: up to 160 MPa / 23200 psi (design-dependent, based on size)
Lightweight aramid braid helps reduce overall hose weight
PTFE inner tube offers excellent chemical compatibility
Flexible construction supports routing in compact or mobile equipment
All values above are based on the catalog reference for JCC-04100-PTFE and vary by hose size.
Core Features
1. PTFE Inner Tube for Broad Chemical Compatibility
The hose uses a Teflon/PTFE straight inner tube, making it suitable for fuels, gases, strong acids, strong alkalis, coolants, lubricants, and many organic solvents.
2. Aramid Braided Outer Layer for Lightweight Reinforcement
The aramid woven outer layer reduces hose weight versus heavier reinforcement options, making it useful for mobile equipment, aerospace-related assemblies, and installations where weight reduction matters.
3. Flexible Performance Across Industrial Applications
With a temperature rating of -65°C to 220°C and multiple size options, this hose can be adapted for fluid transfer lines in transport, hydraulic, chemical, and engineered equipment systems.
| Model | Nominal Size | Inner Diameter (mm) | Outer Diameter (mm) | Working Pressure (psi / MPa) | Burst Pressure (psi / MPa) | Min. Bend Radius (inch / mm) |
|---|---|---|---|---|---|---|
| JCC-04110-PTFE | 3/8" | 10.0 | 13.1 | 5800 / 40.0 | 23200 / 160 | 3.15 / 80 |
| JCC-04113-PTFE | 1/2" | 13.0 | 16.5 | 5437.5 / 37.5 | 21500 / 150 | 5.91 / 150 |
| JCC-04116-PTFE | 5/8" | 16.0 | 19.4 | 4785 / 33.0 | 19140 / 132 | 7.09 / 180 |
| JCC-04119-PTFE | 3/4" | 19.0 | 23.1 | 4241.3 / 29.25 | 16960 / 117 | 11.81 / 300 |
| JCC-04125-PTFE | 1" | 25.4 | 30.5 | 3552.5 / 24.5 | 14210 / 98 | 15.75 / 400 |
How to Select the Right PTFE Aramid Braided Lightweight Hose (Send These Details)
To recommend the correct hose, please send:
Medium to be conveyed
Working temperature and peak temperature
Working pressure and required safety factor
Hose ID or flow requirement
Hose length
Minimum bend radius or installation space
End connection type
Whether the hose will be used in dynamic or static routing
Industry/application scenario
Required quantity and target delivery time
About Us (Manufacturing & Delivery)
We are a specialized PTFE hose manufacturer focused on custom industrial hose solutions. Based on the catalog, our product range covers smooth bore PTFE hose, corrugated PTFE hose, braided PTFE hose, spring-reinforced hose, anti-static PTFE hose, TPU-covered hose, and lightweight aramid braided hose for different industrial applications. We support drawing-based production, sample evaluation, and customized hose assembly delivery.
