The PTFE inner smooth outer corrugated braided hose, model JCC-21100-PTFE, represents a breakthrough in flexible tube technology. This hose combines the chemical resistance of PTFE (polytetrafluoroethylene) with enhanced durability through strategic layering and reinforcement design.
Unlike standard hoses, the PTFE inner smooth outer corrugated braided hose features a sophisticated three-layer structure:
Inner Layer: A smooth PTFE tube that provides an inert, non-reactive surface for fluid transportMiddle Layer: A corrugated exterior made from high-strength 304 stainless steel, offering exceptional pressure resistanceOuter Layer: A 304 stainless steel braided wire reinforcement providing structural integrity and enhanced durability
This innovative design delivers the perfect balance of flexibility and strength while maintaining the chemical compatibility that PTFE is renowned for.
One of the most significant advantages of PTFE is its extraordinary resistance to harsh chemicals. The smooth inner surface of this hose ensures:
Compatibility with strong acids and alkalis
Excellent resistance to powerful oxidizing agents
Safe transport of reducing agents and organic solvents
Inert properties that don't contaminate sensitive fluids
With an operating temperature range from -70°C to +260°C, these hoses excel in both extreme heat and cold environments:
Maintains flexibility in freezing conditions
Resists degradation at high temperatures
Perfect for steam applications and cryogenic services
Reliable performance across seasonal variations
The integration of 304 stainless steel braiding and corrugated design enables impressive pressure ratings, with burst pressures reaching up to 5104 psi for certain configurations.
The smooth PTFE inner surface offers remarkable advantages:
Easy to clean with minimal residue buildup
Resistant to fouling and contamination
Reduced maintenance requirements
Improved product purity for sensitive applications
Despite their strength, these hoses maintain excellent flexibility:
Minimum bending radius as small as 0.75 inches in certain sizes
Allows for tight routing in confined spaces
Reduces installation complexity
Enables efficient system design
The PTFE inner smooth outer corrugated braided hose is available in various dimensions to suit different applications:
| Model | Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Min. Bending Radius |
|---|---|---|---|---|---|
| JCC-21106-PTFE | 1/4" (6.8mm) | 9.6mm | 1276 psi | 5104 psi | 19mm |
| JCC-21108-PTFE | 5/16" (7.9mm) | 10.6mm | 1218 psi | 4872 psi | 19mm |
| JCC-21110-PTFE | 3/8" (10mm) | 13.5mm | 1305 psi | 5220 psi | 25mm |
| JCC-21113-PTFE | 1/2" (13.6mm) | 17.5mm | 870 psi | 3480 psi | 38mm |
| JCC-21125-PTFE | 1" (26.4mm) | 31.7mm | 580 psi | 2320 psi | 75mm |
Custom sizes available upon request
All PTFE inner smooth outer corrugated braided hoses meet international quality standards:
ISO 9001:2015 – Quality Management Systems
FDA 21 CFR 177.1550 – Food-grade compliance
SGS Certification – Third-party quality assurance
Jingcheng (晶诚高科技) is a leading manufacturer of premium PTFE tubing and specialized hose solutions. With facilities in Shenzhen, Guangzhou, and Zhongshan, China, the company has been delivering exceptional quality since 2005. Specialized in PTFE tubes, high-pressure hoses, and custom fluid conveyance solutions, Jingcheng is committed to providing customers worldwide with the most reliable and innovative tubing products available.
For more information about PTFE inner smooth outer corrugated braided hoses and other specialized tubing solutions, visit www.shenzhennjingcheng.com
