选出5~20篇与该产品相关联的文章展示在前台产品详情。 全部分类 搜索 全选 How to Extend the Service Life of PTFE Tubing: Vibration, Wear and Maintenance Electrically Heated Crack Sealing Hose: A Buyer's Guide for Road Maintenance Equipment From Syrup to Chocolate: Heated Hoses in Food and Beverage Processing Why Is Bend Radius Important for PTFE Tubing? Jingcheng Expands Medical Heated Hose Solutions for Temperature-Controlled Healthcare Equipment Applications Under Pressure: The Engineering Behind High-Pressure Heated Hoses Why Is PTFE Tubing Used in High-Purity Applications? Why Industrial Machine Builders Are Moving Toward TPU Covered PTFE Hose Systems Medical-Grade Heated Hoses: The Critical Link in Sterile Fluid Transfer Electric vs. Steam Tracing: Why Electrically Heated Hoses Are Replacing Traditional Methods 确认 1 2 3 4 5 ... 共13页 到第 页 已选择的相关文章： Smooth-ID Corrugated-OD PTFE Hose with 304 Spiral Spring for Steam, Hot Oil and Chemical LinesProcess lines carrying corrosive chemicals, hot air, thermal oil or steam often require two qualities that ordinary tubing cannot combine: a smooth, self-draining inner bore that will not trap residue, and a flexible, crush-resistant body that bends tightly without kinking. JINGCHENG Smooth-ID Corrugated-OD PTFE Hose with 304 Spiral Spring (series JCC-20000-PTFE) integrates a smooth PTFE inner wall, a corrugated outer wall and a 304 stainless steel spiral reinforcing spring for dependable service from -65°C to +260°C. Three-Part Reinforced Structure Smooth PTFE inner bore: Fluid contacts only a flat, seamless PTFE inner wall, ensuring low flow resistance, rapid drainage and easy flushing in food, cosmetic, pharmaceutical and chemical systems. Corrugated outer profile: External ribs give the hose high flexibility, achieving minimum bend radii from 19 mm (0.75") on 1/4" and 5/16" sizes to 75 mm (2.95") on the 1" size. 304 stainless steel spiral spring reinforcement: Embedded along the corrugated profile to support the hose wall against kinking, crushing and pressure pulses, enabling working pressures up to 2.64 MPa (396 psi) and burst pressures up to 8.8 MPa (1276 psi). Wide thermal rating (-65°C to +260°C): Handles sub-zero chemical transfer as well as continuous hot air, hot oil and steam service. Typical Industrial ApplicationsPer the JINGCHENG PTFE hose catalog (JCC-20000-PTFE series), this hose is designed to transport highly corrosive chemicals, hot air, hot oil, steam and related media across the food, cosmetics, chemical and pharmaceutical industries: Corrosive chemical transfer and dosing: Flexible connections for strong acids, alkalis, oxidizers and aggressive solvents where higher pressure and anti-kink support are required. Hot oil and hot air circulation lines: Flexible jumpers on heating platens, drying ovens, mold temperature controllers and thermal fluid skids. Steam utility and equipment lines: Steam supply and condensate connections operating within the -65°C to +260°C temperature window. Food, cosmetics and pharmaceutical processing: Hygienic transfer of oils, creams, lotions, syrups and active ingredients that require a smooth, cleanable PTFE bore and tight equipment routing. Technical Specifications (JCC-20000-PTFE Series) Part No. | Nominal Size | Inner Diameter (mm ±0.3) | Outer Diameter (mm ±0.3) | Working Pressure (psi) | Working Pressure (MPa) | Burst Pressure (psi) | Burst Pressure (MPa) | Min. Bend Radius (inch) | Min. Bend Radius (mm) | JCC-20006-PTFE | 1/4" | 6.8 | 8.35 | 396 | 2.64 | 1276 | 8.8 | 0.75 | 19 | JCC-20008-PTFE | 5/16" | 7.9 | 10.3 | 378 | 2.52 | 1218 | 8.4 | 0.75 | 19 | JCC-20010-PTFE | 3/8" | 10 | 11.93 | 360 | 2.4 | 1160 | 8 | 0.98 | 25 | JCC-20013-PTFE | 1/2" | 13.6 | 15.1 | 270 | 1.8 | 870 | 6 | 1.50 | 38 | JCC-20016-PTFE | 5/8" | 16.7 | 18.3 | 236.83 | 1.63 | 725 | 5 | 1.97 | 50 | JCC-20019-PTFE | 3/4" | 19.8 | 22 | 203 | 1.4 | 609 | 4.2 | 2.48 | 63 | JCC-20025-PTFE | 1" | 26.4 | 29.4 | 180 | 1.2 | 580 | 4 | 2.95 | 75 | Data source: JINGCHENG PTFE Hose Catalog (JCC-20000-PTFE Series). Operating temperature range: -65°C to +260°C. All specifications can be customized according to customer parameters. How JCC-20000 Compares with Other JINGCHENG PTFE Hose Series JCC-20000 vs. JCC-00000 Smooth Bore Tube: Both feature a smooth PTFE inner bore, but JCC-20000 reduces the 1" minimum bend radius from 600 mm down to 75 mm while increasing the 1" working pressure from 0.70 MPa to 1.2 MPa. JCC-20000 vs. JCC-10000 Inner Spiral Convoluted Hose: JCC-10000 has a corrugated inner wall and a 0.2–0.4 MPa pressure rating. JCC-20000 provides a smooth, residue-free inner wall and 304 stainless steel spring support for 1.2–2.64 MPa service. JCC-20000 vs. JCC-21100 Smooth-Bore Convoluted Braided Hose: When even higher pressure (up to 8.8 MPa working pressure) and external abrasion protection are needed with a smooth-bore convoluted core, JCC-21100 adds an outer 304 stainless steel wire braid. Selection, Installation and Customization Guidelines Match size to pressure and flow: Choose from the 7 standard sizes (1/4" to 1" ID) ensuring operating pressure stays within the 1.2–2.64 MPa working pressure rating for that diameter. Prevent torsion and over-bending: Keep bends at or above the 19–75 mm minimum bend radius, avoid twisting the hose during fitting installation, and provide thermal guards on exposed steam or hot oil lines. Custom production to your parameters: JINGCHENG customizes inner/outer diameters, cut lengths, end cuff configurations and fitting assemblies for OEM machinery builders and plant maintenance teams. Contact us with your operating parameters for a quotation. |
