Intro
When applications require the chemical resistance of PTFE but also need a cleaner, more protected outer surface, TPU covered PTFE braided hose is a practical solution. It combines a smooth PTFE inner tube, stainless steel braid reinforcement, and a TPU outer jacket to improve wear protection and reduce contamination on the braid surface.This hose design is widely used for transferring fuels, gases, strong acids, strong alkalis, and aggressive solvents. It is also suitable for demanding hydraulic and pneumatic routing where flexibility, cleanability, and chemical compatibility matter.
Performance Highlights
Temperature range: -70°C to +260°C (design-dependent)
Working pressure: up to 27 MPa / 3916 psi (design-dependent, depending on hose size)
Burst pressure: up to 82 MPa / 11897 psi (design-dependent, depending on hose size)
Smooth TPU outer jacket helps protect the stainless braid from wear and external contamination
PTFE core offers excellent resistance to fuels, gases, acids, alkalis, and many solvents
Low permeability and flexible routing for industrial fluid transfer systems
Core Features
1. PTFE Inner Tube for Broad Chemical Compatibility
The hose uses a smooth PTFE inner tube that is inert to most industrial chemicals and solvents. It is suitable for fuels, gases, strong acids, strong alkalis, and many aggressive media.
2. Stainless Steel Braided Reinforcement
A high-strength 304 stainless steel braid layer provides pressure capability and structural reinforcement for demanding transfer applications.
3. Smooth TPU Outer Jacket
The TPU outer cover helps shield the braid, supports easier cleaning, reduces wear from contact surfaces, and can be customized in different colors for line identification.
| Model | Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Minimum Bending Radius |
|---|---|---|---|---|---|
| JCC-61104-PTFE | 4 mm | 9.4 mm | 27 MPa | 82 MPa | 50 mm |
| JCC-61106-PTFE | 6.35 mm | 11.5 mm | 42 MPa | 126.9 MPa | 75 mm |
| JCC-61108-PTFE | 7.8 mm | 13.5 mm | 19 MPa | 57.9 MPa | 100 mm |
| JCC-61110-PTFE | 9.7 mm | 14.5 mm | 23 MPa | 70.2 MPa | 125 mm |
| JCC-61113-PTFE | 12.7 mm | 18.5 mm | 23 MPa | 68 MPa | 165 mm |
| JCC-61116-PTFE | 15.9 mm | 21.8 mm | 18 MPa | 53.8 MPa | 200 mm |
| JCC-61119-PTFE | 19 mm | 25.1 mm | 15 MPa | 44.8 MPa | 225 mm |
| JCC-61125-PTFE | 25.6 mm | 31.5 mm | 10 MPa | 31 MPa | 300 mm |
About Us (Manufacturing & Delivery)
We manufacture PTFE hose products for industrial applications and support custom production based on actual operating conditions. From material selection and hose forming to reinforcement, assembly, inspection, and shipment, we focus on stable quality, flexible customization, and efficient delivery for OEM and industrial buyers.
