A high temperature high pressure heated hose is designed for special industrial equipment that requires stable heating, strong pressure resistance and reliable fluid transfer under demanding working conditions. In many special industries, the hose must not only transfer media safely, but also maintain temperature stability during operation.
Shenzhen Jingcheng High-tech manufactures customized high temperature high pressure heated hoses for domestic and imported special equipment. This hose is designed with a PTFE inner tube, 304 pressure-resistant steel wire reinforcement and a uniformly distributed heating layer, helping customers achieve safer, more stable and more efficient thermal fluid transfer.
A high temperature high pressure heated hose is a reinforced heated hose used in applications where the transferred medium must be kept at a stable temperature while the pipeline also needs to withstand high pressure.
Unlike ordinary hoses, this product combines:
PTFE inner tube for chemical and temperature resistance
304 pressure-resistant steel wire reinforcement
Uniform heating structure
High-efficiency insulation layer
Customized fittings and electrical configuration
Pressure capability up to 40MPa or higher by customization
This makes it suitable for special industrial equipment, high-pressure heated transfer systems and demanding production environments.
In special industrial applications, hose failure may cause production downtime, leakage, unstable temperature control, equipment damage or higher maintenance cost. Ordinary hoses may not be able to withstand high temperature, high pressure and continuous heating at the same time.
A properly designed high temperature high pressure heated hose helps solve these problems by maintaining stable heating performance while providing strong pressure resistance. It is especially useful for equipment that requires continuous thermal insulation, high-pressure transfer and customized connection with the machine.
The hose can support a working temperature up to 230°C. For higher temperature requirements, the hose can be customized according to the working conditions.
This hose is designed for special high-pressure pipelines. The pressure resistance can reach 40MPa or higher depending on the customized structure, hose size and application requirements.
The inner tube uses PTFE material, which provides excellent temperature resistance, chemical resistance and stable material compatibility in demanding transfer systems.
The hose uses 304 pressure-resistant steel wire reinforcement to improve working pressure, burst pressure and structural reliability.
The heating layer is made with uniformly braided heating elements. This helps reduce temperature differences along the hose inner wall and improves heating stability during operation.
The hose is manufactured with high-insulation materials to reduce heat loss and improve thermal efficiency while considering surface temperature control.
Hose length, inner diameter, pressure rating, voltage, power, sensor type, connector type and electrical connection can all be customized according to equipment requirements.
Our high temperature high pressure heated hose can be used in:
Special industrial equipment
Imported and domestic special machinery
High temperature high pressure pipeline systems
Thermal fluid transfer systems
High-pressure heated material transfer
Special chemical transfer equipment
Industrial heating and insulation systems
Custom production equipment connection
High-pressure process pipelines
Temperature-controlled transfer systems
Item | Available Options |
|---|---|
Product Name | High Temperature High Pressure Heated Hose |
Product Type | Special Industry Connecting Hose |
Inner Tube | PTFE / Teflon inner tube |
Reinforcement | 304 pressure-resistant steel wire |
Heating Structure | Uniformly braided heating element |
Temperature | Up to 230°C |
Pressure | Up to 40MPa or higher by customization |
Voltage | 220V / 110V / 380V / 12V DC / Custom |
Sensor Type | PT100, PT1000, J type, K type, NI120 or custom |
Connector Standard | Metric, British, American or custom |
Customization | Available |
Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | Minimum Bending Radius |
5/16” | 13.3 mm | 113 bar / 1631 psi | 450 bar / 6525 psi | 15 mm |
3/8” | 15.5 mm | 110 bar / 1595 psi | 440 bar / 6380 psi | 20 mm |
1/2” | 19 mm | 88 bar / 1269 psi | 350 bar / 5075 psi | 25 mm |
5/8” | 22.7 mm | 70 bar / 1015 psi | 280 bar / 4060 psi | 30 mm |
3/4” | 27 mm | 65 bar / 943 psi | 260 bar / 3770 psi | 60 mm |
1” | 34 mm | 57.5 bar / 834 psi | 230 bar / 3335 psi | 85 mm |
1-1/4” | 43 mm | 52.5 bar / 761 psi | 210 bar / 3045 psi | 155 mm |
1-1/2” | 49.5 mm | 50 bar / 725 psi | 200 bar / 2900 psi | 200 mm |
Shenzhen Jingcheng High-tech Co., Ltd. is a professional manufacturer of PTFE hoses, PTFE high-pressure hoses, PA hoses and electric heated hoses. Since 2005, we have provided customized hose solutions for pharmaceutical transfer, petroleum transfer, automotive coating production, flue gas sampling, hot melt adhesive systems and other industrial applications.
For special industrial equipment manufacturers and global buyers, we provide factory-direct heated hose solutions with stable quality, flexible customization, short lead time and sample support.
We manufacture heated hoses directly in China, helping customers reduce sourcing cost, shorten the supply chain and improve procurement efficiency.
Special equipment often requires non-standard hose length, pressure, connector, voltage and sensor configuration. We can customize the hose according to drawings, samples or working conditions.
The PTFE inner tube and 304 pressure-resistant steel wire reinforcement help improve the hose’s pressure resistance and long-term reliability.
The uniformly braided heating layer helps maintain stable temperature distribution and reduces the risk of uneven heating.
We support fast response for replacement hoses, urgent projects and customized production. Samples can be provided for testing before bulk order.
